4.00" x 2.00" Swivel Plate Caster with Polyon™ Wheel
Our Polyon wheel is comprised of a polyurethane tread bonded to a solid cast-iron core. It offers a high capacity while also providing floor protection with its non-marking tread. It is resistant to most solvents, oil, grease, annd water.
Great for automotive plants, towlines applications and general warehouse carts.
The 41/42 Series is the economy-priced alternative to our 45/46 Kingpinless Series, offering the same matching swivel and rigid caster configurations at a lower price point. Rated for medium-heavy duty use with capacities up to 1,500 lb, the 41/42 Series is an excellent cost-effective choice for demanding industrial applications where the full capacity of the 45/46 is not required.
Specifications
| Caster Type | Swivel |
|---|---|
| Mount Type | Top Plate |
| Top Plate Size | 4" x 4-1/2" |
| Bolt Hole Pattern | 2-5/8" x 3-5/8" Slotted to 3" x 3" |
| Wheel Diameter | 4.0" |
| Tread Width | 2.0" |
| Wheel Name | Polyon™ |
| Wheel Tread Material | Polyurethane |
| Wheel Core Material | Cast Iron |
| Tread Profile | Flat |
| Wheel Color | Red |
| Wheel Durometer | Shore A 95 ( /-5) |
| Bearing Type | Sealed Precision Ball Bearing |
| Non-Marking Tread | Yes |
| Overall Height | 5.625" |
| Load Capacity | 800 lb |
| Duty Rating | Medium-Heavy Duty |
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Quick Order
Matching Casters
Casters that can be used on the same application. These casters match all specifications except caster type.
4.00" x 2.00" Swivel Plate Caster with Polyon™ Wheel
41PU40JV6017YY
- 4" x 4-1/2" Plate
- Sealed Precision Ball Bearing
- 800 lb Cap.
4.00" x 2.00" Rigid Plate Caster with Polyon™ Wheel
42PU40JV6017YY
- 4" x 4-1/2" Plate
- Sealed Precision Ball Bearing
- 800 lb Cap.
