4.00" x 2.00" Swivel Plate Caster with Semi-Steel Wheel
Made from a mixture of steel and cast iron; this Semi-Steel wheel offers a strong, durable and cost-effective solution for heavy loads. Hard tread rolls easily and offers high abrasion resistance. Tread face is precisely machined for a smooth and centrical ride; tread edge is machined round.
A good choice for heavy loads in manufacturing and warehousing; especially on rough concrete and other rough surfaces.
The 41/42 Series is the economy-priced alternative to our 45/46 Kingpinless Series, offering the same matching swivel and rigid caster configurations at a lower price point. Rated for medium-heavy duty use with capacities up to 1,500 lb, the 41/42 Series is an excellent cost-effective choice for demanding industrial applications where the full capacity of the 45/46 is not required.
Specifications
| Caster Type | Swivel |
|---|---|
| Mount Type | Top Plate |
| Top Plate Size | 4" x 4-1/2" |
| Bolt Hole Pattern | 2-5/8" x 3-5/8" Slotted to 3" x 3" |
| Wheel Diameter | 4.0" |
| Tread Width | 2.0" |
| Wheel Name | Semi-Steel |
| Wheel Tread Material | Steel |
| Wheel Core Material | Steel |
| Tread Profile | Flat |
| Bearing Type | Roller Bearing |
| Overall Height | 5.625" |
| Load Capacity | 700 lb |
| Duty Rating | Medium-Heavy Duty |
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Quick Order
Matching Casters
Casters that can be used on the same application. These casters match all specifications except caster type.
4.00" x 2.00" Swivel Plate Caster with Semi-Steel Wheel
41SS40JS0417YY
- 4" x 4-1/2" Plate
- Roller Bearing
- 700 lb Cap.
4.00" x 2.00" Rigid Plate Caster with Semi-Steel Wheel
42SS40JS0417YY
- 4" x 4-1/2" Plate
- Roller Bearing
- 700 lb Cap.
