6" x 2" Swivel Plate Caster with Ergolastomer™ Wheel
Our Ergolastomer wheel is a solid cast polyurethane-elastomer tread which is mechanically locked to a Glass-Filled Nylon core. This caster is very strong and durable with high impact and abrasion resistance. Its sealed precision ball bearings and crowned tread significantly helps reduce rolling resistance, swiveling action and push/pull forces required to move. These wheels are maintenance free and non-marking with virutally no tread wear.
The 47/48 Series offers matching swivel and rigid casters rated for medium-heavy duty use with capacities up to 2,000 lb. Constructed with 1/4″ thick top plates from hot forged ASTM1045 steel with legs also formed from 1/4″ thick steel.
Specifications
| Caster Type | Swivel |
|---|---|
| Mount Type | Top Plate |
| Top Plate Size | 4-1/2" x 6-1/4" |
| Bolt Hole Pattern | 2-7/16" x 4-15/16" Slotted to 3-3/8" x 5-1/4" |
| Wheel Diameter | 6.0" |
| Tread Width | 2.0" |
| Wheel Name | Ergolastomer™ |
| Wheel Tread Material | Polyurethane |
| Wheel Core Material | Polyurethane |
| Tread Profile | Round |
| Wheel Color | Gray |
| Wheel Durometer | Shore 68 ( /-5) |
| Bearing Type | Sealed Precision Ball Bearing |
| Non-Marking Tread | Yes |
| Overall Height | 7.5" |
| Load Capacity | 2000 lb |
| Duty Rating | Medium-Heavy Duty |
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Quick Order
Matching Casters
Casters that can be used on the same application. These casters match all specifications except caster type.
6" x 2" Swivel Plate Caster with Ergolastomer™ Wheel
47HU60JI6419YY
- 4-1/2" x 6-1/4" Plate
- Sealed Precision Ball Bearing
- 2000 lb Cap.
6" x 2" Rigid Plate Caster with Ergolastomer™ Wheel
48HU60JI6419YY
- 4-1/2" x 6-1/4" Plate
- Sealed Precision Ball Bearing
- 2000 lb Cap.
