3" x 1-13/16" Swivel Black Plate Caster with IronMan™ Wheel
Regular price
$79.56
Sale price
Regular price
Shipping calculated at checkout.
5A Series low-profile swivel casters are engineered to carry high loads at the lowest possible mounting height. A double ball bearing swivel raceway keeps rotation smooth and consistent under load, the 1/2" axle resists deflection, and the black-coated finish holds up in demanding environments. NSF Listed and RoHS compliant.
The high-impact polymer wheel absorbs shock and resists chemicals, carrying the highest capacity in the series at 1200 lb.
Specifications
| Caster Type | Swivel |
|---|---|
| Mount Type | Top Plate |
| Top Plate Size | 3-1/8" x 4-1/8" |
| Bolt Hole Pattern | 2-3/8" x 3-3/8" |
| Wheel Diameter | 3.0" |
| Tread Width | 1.8125" |
| Axle Size | 0.5" |
| Wheel Name | IronMan™ |
| Wheel Tread Material | Polymer |
| Wheel Core Material | Polymer |
| Tread Profile | Flat |
| Wheel Color | Black |
| Wheel Durometer | Shore D 78-82 |
| Bearing Type | Precision Ball Bearing |
| Non-Marking Tread | Yes |
| Overall Height | 4.09375" |
| Load Capacity | 1200 lb |
| Duty Rating | Medium Duty |
