8" x 2" Total-locking Plate Caster with MaxRok™ Wheel
Our Maxrok wheel is a ultra-strong injection molded Glass-Filled Nylon wheel. Has the same weight capacity of steel, yet it's incredibly light-weight. Extreme impact strength, abrasion and compression resistance. Completely washable & steam cleanable. It's not effected by grease, oils, salt, brine, blood, as well as most chemicals and cleaning solutions.
The corrosion resistant material makes this the perfect wheel for outdoor applications. Commonly used in food processing plants and greenhouse operations.
The 27/28/DT/FT medium duty series is one of our most popular series of casters. This series offers matching swivel, rigid, single-pedal total-locking and dual-pedal total-locking casters with capacities up to 1,250 lb. These casters use a 2" wide wheel as standard.
Specifications
| Caster Type | Total-locking |
|---|---|
| Mount Type | Top Plate |
| Top Plate Size | 4" x 4-1/2" |
| Bolt Hole Pattern | 2-5/8" x 3-5/8" Slotted to 3" x 3" |
| Wheel Diameter | 8.0" |
| Tread Width | 2.0" |
| Wheel Name | MaxRok™ |
| Wheel Tread Material | Glass-Filled Nylon |
| Wheel Core Material | Glass-Filled Nylon |
| Tread Profile | Crowned |
| Wheel Color | Black |
| Wheel Durometer | Shore D 85 ( /-5) |
| Bearing Type | Sealed Precision Ball Bearing |
| Non-Marking Tread | Yes |
| Overall Height | 9.5" |
| Load Capacity | 1250 lb |
| Duty Rating | Medium Duty |
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Quick Order
Matching Casters
Casters that can be used on the same application. These casters match all specifications except caster type.
8" x 2" Swivel Plate Caster with MaxRok™ Wheel
27MA80JB6017YY
- 4" x 4-1/2" Plate
- Sealed Precision Ball Bearing
- 1250 lb Cap.
8" x 2" Rigid Plate Caster with MaxRok™ Wheel
28MA80JB6017YY
- 4" x 4-1/2" Plate
- Sealed Precision Ball Bearing
- 1250 lb Cap.
8" x 2" Total-locking Plate Caster with MaxRok™ Wheel
DTMA80JB6017YY
- 4" x 4-1/2" Plate
- Sealed Precision Ball Bearing
- 1250 lb Cap.
8" x 2" Total-locking Plate Caster with MaxRok™ Wheel
FTMA80JB6017YY
- 4" x 4-1/2" Plate
- Sealed Precision Ball Bearing
- 1250 lb Cap.
