4.02" OAH Swivel Plate Caster with Nylon Wheel
Solid injection-molded Nylon wheel offers high load capacity, low rolling resistance, and resistance to most industrial chemicals, oils, and solvents. Non-marking on hard surfaces. Best suited to smooth, clean floors — Nylon transmits shock and vibration to the chassis, so it is not recommended for rough or uneven terrain.
Our LV Series consists of swivel casters with an integrated leveling mechanism, allowing equipment to be raised off its wheels and rest on a stable footpad when stationary. Built around an aluminum die-cast rig with a forged steel zinc-plated top plate, double ball bearing raceways for smooth swivel action, and an AC rubber leveling cushion pad that compensates for constant pressure and temperature change. Rear-accessible thumb wheel adjusts the leveling pad without removing the caster from the equipment. NSF Listed and RoHS Compliant. Ideal for telecom and broadcasting consoles, lab and research equipment, medical equipment, office business machines, electronic equipment, food and retail equipment, conveyor stands, work stations, and assembly machinery.
Specifications
| Caster Type | Swivel |
|---|---|
| Mount Type | Top Plate |
| Top Plate Size | 3.54" x 3.54" |
| Bolt Hole Pattern | 2.77" x 2.77" |
| Wheel Diameter | 2.44" |
| Tread Width | 1.13" |
| Wheel Name | Nylon |
| Wheel Tread Material | Nylon |
| Wheel Core Material | Nylon |
| Tread Profile | Crowned |
| Wheel Color | Black |
| Wheel Durometer | Shore D 85 (+/-5) |
| Bearing Type | Plain Bore |
| Non-Marking Tread | Yes |
| Overall Height | 4.02" |
| Adjustment Range | '+0.59" |
| Load Capacity | 1300 lb |
| Duty Rating | Medium Duty |
